5182FL Grade 1 Lock Features:
- ANSI CODE: F75
- Latch retracted by knobs/levers at all times
- 5100 Standard: Certified by ANSI A156.2-2003
- UL Listed: Meets UL 3 hours fire rating
- 6-Pin cores with the capacity to retrofit all 6-Pin best style lock sets
- Wide variety of compatible lock sets for other famous brands like Schlage, Arrow, Best, Falcon, and KSP
- Clutch Function: The exterior lever has a release to prevent heavy impact while pressing the lever at locking position
- Roller Retractor: The retractor is equipped with a roller to enhance mechanical reliability and durability
- Finish: US26D, US32D
- Lever: Zinc, 4-29/32” (125mm) from lock center to lever end
- Rose: Φ 3-17/32” (90mm)
- Door Thickness: 1-3/8” to 2” (35mm to 51mm)
- Backset: 2-23/64” or 2-3/4” (60mm or 70mm)
- Concealed Screws: The screws are hidden (concealed), not exposed on the exterior side
